Output
  Input




10 MHz





  1PPS from GPS/GNSS
  or
  GPS/GNSS receiver inside

Accuracy @ shipment

typ. < 5x11 at 25c

Tempco
  Temp
  Aging

+1E-10
  -10 to 55C
  < 5E-11/mth, typ. < 3E-11/mth

  -32 to 65C
  < 3E-11/mth or 2E-10/yr

Stability (ADEV)
  1s
  10s
  100s

  2E-11
  8E-12
  2E-12

  1E-11
  3E-12
  1E-12

Phase noise @ 10 MHz
  1 Hz
  10 Hz
  100 Hz
  1 kHz
  10 kHz

(dBc/Hz)
  -95
  -120
  -140
  -145
  -150

  -103
  -133
  -153
  -158
  -161

Holdover

< 1µs/24hr*, < 7µs/week*
  < 3µs/24hr**
  < 7µs/24hr***
  *temp profile +2C
  **temp profile within 20C
  ***temp profile within 40C

Warm-up time @ 25C

12 min, 5E-10

< 5-7 min(a)
  25 min(b)

Power (operating)


  Voltage
  Warm-up

< 7-14W


  24V
  < 38W

< 40-50W(a)
  < 24W(b)
  +2W with GPS/GNSS inside
  12V
  < 30W

Size (WxHxL)

128x95x38.1mm | 5.3x3.74x1.5"

Weight

525 g | 1.15 lbs

Vibration sensistivity

see spec

Low g sensitivity

n/a
